Flat Pack Shipping Containers 10ft / 3.3m x 2.3m
Pricing
A 10ft (3.3m class) flat-pack kabin offering more workspace while staying suitable for restricted access delivery. Supplied as a complete kit for fast assembly with basic tools, with insulated panels and an improved locking system as standard. Demountable for relocation, stackable and linkable to create larger office areas.
10ft flat pack kabin for restricted access
This 10ft flat pack kabin provides insulated, secure workspace where delivery and access are difficult. Designed as a man portable office building, components can be carried through narrow passageways and alleys, with no lifting gear required for assembly. Supplied as a complete kit, it is quick to erect using only basic tools - just a socket set. The unit is demountable for relocation, stackable, and can be linked to create larger office areas with the appropriate kits.
Key benefits
- Fully insulated walls and roof for a comfortable workspace
- Robust construction with stronger wall panels
- Improved double locking system as standard
- Man portable components for tight access sites
- Quick assembly, ready for use in less than an hour
- Stackable and modular linking options available
Why it works so well
Where this kabin is a great fit
- Restricted access sites and narrow entry routes
- Construction projects needing office or meeting space
- Site welfare and admin buildings
- Locations where crane delivery is impractical
Why customers choose it
- Insulated 50mm sandwich panel system
- Door and window positions can be configured in the frame
- Demountable for storage or relocation
- Stackable with add on kits
- Surface mounted electrics can be added, optional kit available
Technical specification
| Unit length | 3.3m (10ft class) |
|---|---|
| External dimensions (including gutter) | 3388mm x 2383mm |
| Overall width | 2383mm including gutter, 2302mm excluding gutter |
| Height (assembled) | 2350mm external, 2103mm internal |
| Height (flat packed) | 570mm |
| Walls | Vacuum bonded sandwich panels with 50mm polystyrene insulation, outer 0.60mm galvanised steel powder coated RAL6005, inner 0.60mm galvanised steel powder coated RAL9002 |
| Roof | Outer 0.60mm box profile galvanised steel with two gutters, inner insulated sandwich panel with 50mm polystyrene, snow load 100kg/m2 evenly distributed |
| Chassis and frame | Hot dipped galvanised box profile steel, corner columns 1.5mm cold formed steel, powder coated RAL6005 |
| Floor | 18mm OSB board with 2mm PVC linoleum, no insulation in floor, floor load 250kg/m2 evenly distributed |
| Door | Powder coated galvanised steel, 0.60mm thick, replaceable euro cylinder lock |
| Window | uPVC double glazed (4+9+4) inward opening, 805 x 1135mm |
| Colour | External green RAL6005, internal white RAL9002 |
| Electrical | No electrics fitted as standard, designed for surface mounted installation, optional electrical kit available |
| Weight reference | Chassis complete 240kg, Chassis section 66kg, Blank wall panel 27kg, Window panel 52kg, Door panel 65kg, Inner roof panel 27kg, Outer roof panel 74kg |
Why choose flat-pack containers
Flat-pack cabins arrive as compact panels, then assemble on site. They are ideal when access is tight, cranage is not practical, or you want a unit you can relocate later. Explore the full flat-pack range or use Quick Quote for the fastest advice and pricing.
Quick assembly on site
Build with basic tools in hours, not days, once your base is level. Compare sizes and layouts in our flat-pack container range.
Secure and site-ready
Galvanised steel panels with robust, lockable doors help protect equipment and stock. For controlled entry points, see the flat-pack security kiosk.
Delivered flat-packed for tight access
Compact delivery and man-portable panels suit restricted sites and back-of-house installs. Need a warmer internal environment? View insulated stores.
Demountable and relocatable
Reconfigure or move your unit as your site changes, without committing to a permanent structure. For short-term deployments, consider a pop-up container.
12 Month Guarantee
All flat-pack units include a 12-month fair wear and tear guarantee. If you have questions about suitability, access, or base preparation, contact our team or send details via Quick Quote.
Request a Quick Quote!
Contact our sales team for your no-obligation quote, including delivery!
Quick and easy assembly
See our assembly guide for the full step-by-step process. Flat-pack Kabins (often supplied as an Expandakabin kit) use a modular chassis, corner posts, ring beams and interlocking wall panels, with flexible door and window positioning selected during the build.
Best practice before you start:
- Assemble on level, solid ground for correct wall and roof alignment.
- Tools: 13mm and 19mm spanners or sockets, plus a screwdriver.
- Hand tighten first; fully tighten all fixings once complete.
- Keep corner sections and transit fixings safe for re-use.
- Remove protective membrane from wall panels before fitting.
- Decide door and window position early (before completing the wall runs).
- Use joining strips and ring beams to lock panels in place as you go.
- Roof panels slot in place; seal external joints with the supplied self-adhesive tape.
Handling and relocation: If the Kabin is already delivered in its final position, do not disassemble the floor chassis. If you need to move components through restricted access, the chassis can be broken down into sections and reassembled at the final location.
After assembly: Fit door handle and window fixings, install roof fixing brackets, seal roof joints externally, then re-check all bolts are tight. The assembled unit can be lifted and repositioned using suitable equipment, but additional fixings may be required - follow your site H&S procedures.
